NATS and Airbox launch Aware GPS device to help pilots avoid controlled airspace.
This device, quite unlike anything
else currently available, provides a low cost moving map display using a
4.3" backlit sunlight readable screen and contains the latest UK ICAO
1:500,000 chart.
In essence the devices primary function is to warn when the pilot is approaching, and then about to enter, restricted airspace.
Alerts include:
- Controlled Airspace (Control Zones, Control Areas and Airways)
- Aerodrome Traffic Zones
- Danger Areas and Prohibited Areas
- Restricted Airspace (Temporary) – e.g. air shows and Red Arrows displays
- Transponder Mandatory Zones
- MATZ
- ATZ
- GVS
- PSL
- HIRTA
The Aware device comes with the ICAO
1:500,000 scale UK chart preloaded on the supplied SD card, with more
charts available on the manufacturer’s web site. For those pilots who
prefer them, including myself, the 1:250,000 scale charts are available
to download for a fee.
NATS airspace definition updates are free and digital chart updates are available at a very reasonable £24.99 per chart.
Inside the box
Once you open the small box you will
find the unit itself. Well constructed with a metal chassis. the full
list of contents includes:
 |
- Aware GPS Unit
- 12/24v cigarette lighter power adapter
- 240v power adapter
- USB Cable for computer connection
- Windscreen suction mount
- Instruction pamphlet
- Dimensions 12cm x 8cm x 1.5cm
- Weight 170g
|
The unit itself is slightly wider than my iPhone, the same height, and slightly thicker.
Although the unit will run for about 1hr on its internal
battery, it is recommended that external power is used. If cockpit
power is not available as may well be the case if you are using school
aircraft or indeed any that do not have provision for accessory power
then the Aware device can be powered from an external battery pack via
mini-USB. There are a great many solutions but Aware sell the
PowerMonkey, a device we have reviewed (
see here) which works very well.
The device
Once
the unit has been charged up, it takes around 20 seconds to display the
‘Disclaimer’ screen. After acknowledging that you are taken straight
onto the main screen with the map display.
Indoors it the receiver was sensitive
enough to receive a good GPS signal on occasion but obviously this
device is supposed to be used outdoors and in clear view of the sky.
After several minutes outside, I
received a good GPS fix and the device displayed my location on the map
accompanied by a co-ordinates readout on the bottom left of the screen.
The aircraft icon on the screen turns
bright green when a GPS fix has been established. In addition, the
Altitude/Flight Level is displayed (more of this later on in the
review).
There are
+ and
–
icons at bottom left which control map zoom functions. The device
comes with a small stylus, possibly a relic of the unit's PND origins.
Using a stylus would soon become very fiddly when flying but I found
that my fingers were perfectly sufficient!
Main Display
The other two icons in the bottom right
corner are for centering the map with the current GPS position if you
have moved the map away from the current location, and an
! button which leads to the "Emergency Information" screen which provides the following information:
- Emergency transponder codes
- 7500: Unlawful Interference
- 7600: Radio Failure
- 7700: General Failure
- Emergency frequency: 121.5Mhz
- Your current distance from neartest airfield, heading and current UTC time
Emergency Information Screen
On top is the On/Off button. On the left hand side of the unit you will find:
- Mini-USB connector for power/data
- 3.5mm headphone socket for connection to a headset or external speaker
- AV in socket
- SD card slot
- Reset button
How does it work?
With the device switched on, GPS fix
obtained device and chart loaded the Aware GPS calculates your location
and displays it on the chart.
It then takes your heading and
altitude/flight level and warns you if you are approaching any
applicable controlled/ restricted/ dangerous airspace. I use the work
‘applicable’ because the device takes your altitude/ flight level into
account and warns you about any possible airspace incursions that apply
to you at that level only.
For example, flying along at 5000 feet,
you do not get warned of controlled airspace ahead of you that is only
controlled up to 4000 feet as you are not going to enter that controlled
area.
The screen shots demonstrates this
quite clearly. The device has a 500 feet vertical warning buffer,
meaning airspace 500 feet above or below you will also be warned
against!
In the screen shot above right, my
height above ground level is 207 feet when this photo was taken. You can
quite clearly see the Newcastle Control Zone highlighted in bright
green. This is because this portion of the control zone is from SFC
(surface) to FL 105 (10,500 feet). With myself being at 207 feet, if I
were flying here, I could possibly penetrate this controlled area. If
you look towards the coast, to the right of the two displayed high
obstacles, you will see the extensions of the controlled airspace. These
do not start at the surface, but at 1500 feet and 3000 feet
respectively. Therefore, these zones are not highlighted as my current
altitude/ flight level does not currently threaten that portion of the
control zone.
What happens if I am heading towards controlled airspace at an altitude that would penetrate the controlled zone?
So, you are flying along in the cruise
nicely and become slightly off course over time and drift towards an
area that is controlled airspace. First thing that you would notice on
approaching the controlled airspace is that the area concerned will now
be highlighted in red, and emit an audible three loud, short ‘pips’. In
the top right of the screen will be displayed information about the
airspace that is being warned about. This includes information on:
- Class of airspace
- Name of airspace
- Restriction levels
- Distance to the airspace
As you enter the airspace, the device
will emit two loud and longer ‘pips’ and the red information box from
the top right of the screen will move down to the bottom of the screen.
What about obstacles?
The device will warn about tall obstacles in the same way as for controlled airspace.
The parameters for warnings are:
- Airspace warning valid between sea level – 10,000 feet
- Airspace warning range is 10 minutes
- Vertical warning buffer is 500 feet
- Obstacle warning radius is 0.5 Nautical Miles
Conclusion
The device performs well, with both
audible and visible warnings of upcoming controlled airspace. A distance
to the alerted zone is also given. Furthermore, a track line is also
drawn which shows the current track you are on when heading into
controlled airspace. This is a good feature as it shows the pilot where
they are about to cross the controlled airspace, and therefore which
direction to alter the course to in order to avoid ‘busting’ the
airspace.
The unit is also capable of being used
as a navigation device, just like a car GPS system. The Aware +
includes navigation for £249.00 inc VAT or it can be purchased later
as a navigation upgrade for £119 inc VAT. The navigation upgrade was not
available for this review.
In conclusion, this is a great piece of
equipment which would aid even the most experienced pilot flying VFR in
the UK. The initial outlay for the device at £149.00 inc VAT makes it
an absolute bargain and one that every pilot ought to consider.
As it also comes with free NATS
airpsace definition updates and low cost chart updates it is remarkable
value and so deservedly earns our PocketGPSWorld
Highly Recommended award.
